ITECH IT-M7700 Series
Compact AC Power Supply series with power options
Images for illustrative purposes only. Please refer to product details. Click on the main image for a larger view and to see image descriptions.
- AC, DC, AC + DC output modes with DC voltage offset in AC + DC mode
- Built-in AC power meter with powerful functions
- Built-in waveform database, including 30 harmonic distortion waveforms
- List mode. Can be used to simulate real world AC working conditions including instantaneous power interruption (via PC software)
- Arbitrary waveform output capability with user customizable waveforms
- Harmonic analysis and simulation functions
- Surge/Trap waveform functions
- Front and rear edge dimmer phase dimming function
- Settable output waveform start/stop phase angle
- Higher voltage available by two units in series connection (IT-M7721/7722/7722E/7722D/7723D/7723E only)
- Three phase output available by three units Y-type external connections (IT-M7721/7722/7722E/7722D/7723D/7723E only)
- Standard USB/LAN interface, optional GPIB, RS232 + CAN or Analogue + RS485 interface modules.
The M7721L and M772L are simplified versions and don't support several of the above functions.
Product Variants
| Model | Price | |
|---|---|---|
IT-M7721Compact AC Power Supply 300V/3A/300VA ,1φ, 1U ½ rack |
POA | |
IT-M7721DCompact AC Power Supply 300V/3A/300VA ,1φ, 2U ½ rack |
POA | |
IT-M7721LCompact AC Power Supply 300V/3A/300VA ,1φ, 1U ½ rack |
POA | |
IT-M7722Compact AC Power Supply 300V/6A/600VA ,1φ, 1U ½ rack |
POA | |
IT-M7722DCompact AC Power Supply 300V/6A/600VA ,1φ, 2U ½ rack |
POA | |
IT-M7722ECompact AC Power Supply 300V/7.5A/750VA , 2U ½ rack |
POA | |
IT-M7722LCompact AC Power Supply 300V/6A/600VA ,1φ, 1U ½ rack |
POA | |
IT-M7723Compact AC Power Supply 300V/12A or 600V/6A 1.2kVA , 1U |
POA | |
IT-M7723ECompact AC Power Supply 300V/15A 1.5kVA , 2U ½ rack |
POA |
Data Sheet or Brochure| Model | Description | Price | |
|---|---|---|---|
|
IT-E1205 |
GPIB communication card for IT-M series | POA | |
|
IT-E1206 |
USB communication card for IT-M series | POA | |
|
IT-E1207 |
RS232/CAN communication card for IT-M series | POA | |
|
IT-E1208 |
Analog/RS485 communication card for IT-M series | POA | |
|
IT-E1209 |
USB communication card for IT-M series | POA |
| Series | Model | Price | |
|---|---|---|---|
|
IT-E154A |
POA | ||
|
IT-E154B |
POA | ||
|
IT-E154C |
POA |
