ITECH IT8300 Series
DISCONTINUED - Regenerative DC Electronic Load with models from 3.5kW to 73.5kW
Images for illustrative purposes only. Please refer to product details. Click on the main image for a larger view and to see image descriptions.
This range is discontinued. Please see the IT8000 series instead.
- Voltage range: 80 V / 800 V
- Stand-alone input current up to 3570A
- Stand-alone input power up to 73.5KW
- Support master-slave paralleling, current equalized distribution, maximum output power up to 105 kW or more 1
- Energy-regenerative efficiency Max. 95% 2,3
- 3U size, high power density up to 10.5 kW
- On-grid electricity accumulation function
- Automatic grid-state detection, achieve reliable on-grid function, anti-islanding protection
- 4 testing modes: CC/CV/CR/CP Dynamic loading mode Battery test function, automatic test function, short circuit test function
- Multiple parameters measurement & display: Vdc, Idc, Pdc, Vac, Pac, Fac, Wac
- With pre-charging function, prevent dc loading current overshoot
- Full protection: OVP/OCP/OPP/OTP/ACP and power grid fault protection, fault storage
- Built-in standard LAN/USB/RS232 / RS485 / CAN communication interface, support SCPI protocol
Note 1: Please consult with ITECH for higher power requirement
Note 2: Efficiency up to about 95% for 800V, efficiency up to about 94% for 80V
Note 3: The regenerative power is for in-plant reuse, not for feeding back to the public grid
